Electrical Infrared Inspections
Infrared thermography is a fast, non-contact method for identifying abnormal heating on energized electrical equipment. Most electrical failures are preceded by elevated temperature caused by loose connections, overloads, phase imbalance, deterioration, or abnormal contact resistance. Infrared surveys support predictive maintenance by finding developing issues early—before they become downtime, damage, or safety events.
Scope
Common applications and equipment covered.
Distribution Equipment
Switchgear, switchboards, panelboards, MCCs, bus duct, disconnects, fused switches, and critical feeders.
Transformers & Conductors
Transformer terminations, cable lugs, splices, terminations, and bus connections where access allows safe imaging.
Protection & Controls
Protective relays, CT/VT circuits (as accessible), control power components, and heat-related control cabinet issues.
Rotating Equipment
Motor starters, contactors, and connections supporting process motors, including MCC buckets and drive cabinets.
VFDs & Power Electronics
Line/load terminations, reactors/filters, DC bus components (where visible), and abnormal heating signatures.
Substations
Accessible substation connections and terminations, including disconnects, CTs, PTs, and buswork (site dependent).
How Findings Are Evaluated
We document the problem, quantify it, and provide next steps.
Evaluation approach
- Delta-T analysis: temperature rise above similar components under similar load.
- Load awareness: operating load heavily impacts observed temperature; we note load conditions when available.
- Thermal pattern recognition: loose connection vs overload vs phase imbalance vs harmonics/neutral loading.
- Severity ranking: prioritize corrective actions based on thermal rise and risk.
- Confirmatory recommendations: torque checks, ultrasonic, DLRO, current measurements, or follow-up scans.
Deliverables
Clear reporting that supports maintenance decisions.
Typical report contents
- Visible + infrared images of each anomaly
- Temperature readings and delta-T comparisons
- Emissivity / reflected temperature assumptions (when applicable)
- Asset identification and location references
- Severity ranking and recommended corrective actions
- Summary table of findings for maintenance planning
- Optional: rescan / verification after repairs
IR photo gallery
Process Overview
How an inspection is typically executed.
1) Scope + Access
Confirm target equipment, access windows, energized work constraints, and site safety requirements.
2) Field Survey
Perform systematic scans of equipment while energized, documenting anomalies and thermal patterns.
3) Analysis
Evaluate anomalies using delta-T comparisons, loading context, and pattern recognition.
4) Reporting
Deliver clear findings with severity rankings and recommended corrective actions.
5) Maintenance Support
Optional repair verification scans and trending support for condition-based maintenance programs.
6) Repeat / Trend
Establish baseline and repeat surveys at planned intervals to trend asset health.
Need an Electrical IR Survey?
Tell us what equipment you want scanned (switchgear, MCCs, panels, substations), access constraints, and typical loading. We’ll scope the inspection and return a quote.
